Ford Falcon BA BF XR6 Turbo XR8 Twin Port Exhaust Flange Gasket FDG030R

FDG030R exhaust flange gasket is a replacement twin-port flange gasket designed for selected Ford Falcon BA and BF performance exhaust applications, including XR6 Turbo and XR8.

The gasket features two 63mm (2.5") exhaust openings, a three-bolt flange pattern and fire-ring construction. It is suitable for use with compatible factory and replacement exhaust flange connections and also matches FPBA2213 and FPBA2214 flange plates.

Key Features

• OE-quality replacement exhaust flange gasket
• Twin-port design
• Two 63mm (2.5") exhaust openings
• Three-bolt flange pattern
• Fire-ring construction
• Approximately 1.8mm thick
• Suitable for selected Ford Falcon BA / BF performance exhaust applications
• Suits flange plates FPBA2213 and FPBA2214

Construction

• Design: Twin-port exhaust flange gasket
• Centre Hole Size: 63mm x 2
• Bolt Pattern: 3 bolt
• Lower Bolt Hole Centres: Approximately 144mm
• Thickness: Approximately 1.8mm
• Fire Ring: Yes

Additional Options

• FPBA2213: Compatible exhaust flange plate
• FPBA2214: Compatible exhaust flange plate
• Additional exhaust flange gaskets and fabrication components are available separately

Vehicle Fitment

• Make: Ford
• Model: Falcon
• Series: BA / BA Mk II / BF / BF Mk II
• Approx. Model Range: 2002-2008
• Applications: Selected XR6 Turbo / XR8 and compatible twin-port exhaust systems
• XR6 Turbo Engine: 4.0L turbocharged DOHC inline six
• XR8 Engine: 5.4L BOSS V8

Fitment Notes

FDG030R is a three-bolt twin-port gasket with two 63mm exhaust openings. Before ordering, compare the gasket dimensions and bolt pattern with the existing exhaust flange, particularly where the exhaust system has previously been modified or replaced.

The gasket is also suitable for compatible exhaust fabrication using FPBA2213 and FPBA2214 flange plates.

When replacing an exhaust flange gasket, clean both flange faces thoroughly and remove remaining gasket material, carbon and corrosion before assembly. Check that the flange faces are flat and undamaged.

What’s Included

• 1 x FDG030R twin-port exhaust flange gasket

Recommended With

• FPBA2213 – compatible exhaust flange plate
• FPBA2214 – compatible exhaust flange plate
• New flange bolts and nuts where existing fasteners are damaged or heavily corroded

Warranty & Compliance

FDG030R is intended as a replacement exhaust flange gasket for compatible applications using the specified three-bolt twin-port 63mm flange configuration. Always compare the dimensions and bolt pattern with the existing exhaust connection before installation.

FAQ

What vehicles does FDG030R suit?
FDG030R is used on selected Ford Falcon BA and BF exhaust applications, including XR6 Turbo and XR8, as well as other exhaust systems using the same twin-port flange configuration.

What size are the exhaust openings?
FDG030R has two 63mm (2.5") exhaust openings.

What is the bolt pattern?
FDG030R uses a three-bolt flange pattern. The lower bolt-hole centres are approximately 144mm.

How thick is FDG030R?
The gasket is approximately 1.8mm thick.

Does FDG030R have fire rings?
Yes. FDG030R uses a fire-ring design around the exhaust openings.

Which flange plates suit FDG030R?
FDG030R is listed to suit exhaust flange plates FPBA2213 and FPBA2214.
