Wildcat Headers WILD276A – Toyota Hilux VZN167 VZN172 3.4L V6 5VZ-FE Auto 2002–2005

Wildcat WILD276A exhaust headers (extractors) are designed for selected Toyota Hilux VZN167 and VZN172 4WD models from 2002 to 2005 fitted with the 3.4L V6 5VZ-FE petrol engine and automatic transmission.

Manufactured in Australia, WILD276A features an interference header design for street performance applications. The combination of 1.58" primary pipes, 2.00" secondary pipes and 2.50" outlets is designed to improve exhaust gas flow, torque, throttle response and usable engine performance.

Important: WILD276A suits automatic transmission models only. For manual transmission models see WILD276M.

Key Features

• Australian made Wildcat performance headers
• Interference design for street performance applications
• Designed for selected Toyota Hilux VZN167 / VZN172 4WD models
• Designed for the 3.4L V6 5VZ-FE petrol engine
• Automatic transmission only
• 1.58" primary pipes
• 2.00" secondary pipes
• 2.50" outlets
• Designed to improve exhaust flow, torque, throttle response and engine performance
• Not direct fit – exhaust fabrication/modification required

Vehicle Fitment

• Make: Toyota
• Model: Hilux
• Chassis: VZN167 / VZN172
• Year Range: 2002–2005
• Engine: 5VZ-FE
• Capacity: 3.4L
• Configuration: V6 Petrol
• Drive: 4WD
• Transmission: Automatic Only

Header Specifications

• Brand: Wildcat
• Part Number: WILD276A
• Header Design: Interference
• Primary Pipe Size: 1.58"
• Secondary Pipe Size: 2.00"
• Outlet Size: 2.50"
• Finish: Heat-resistant paint rated to 600°C
• Application: Street Performance
• Manufacture: Australian Made
• Installation: Not Direct Fit – exhaust fabrication/modification required

Construction

• High-quality steel tubing with strong welded construction
• Formed pipework designed for efficient exhaust gas flow
• Heat-resistant paint finish rated to 600°C for added protection and durability
• Australian made

Automatic vs Manual Transmission

WILD276A is specifically designed for automatic transmission applications. If your Hilux is fitted with a manual transmission, see Wildcat WILD276M. Transmission type should be confirmed before ordering.

Important Installation Information

WILD276A is not a direct-fit installation. Exhaust fabrication and modification are required to connect the headers correctly to the vehicle's exhaust system. Professional installation by an experienced exhaust workshop is recommended.

Fitment Notes

What's Included

• Wildcat WILD276A header / extractor assemblies
• Outlet connection components as supplied

Recommended With

• New exhaust manifold/header gaskets
• High-temperature exhaust gasket sealant
• Replacement manifold studs and nuts where required
• Suitable 2.50" exhaust components for completing the installation

Installation Tips

• Lubricate manifold studs, nuts and exhaust fasteners with WD-40 or a similar penetrating lubricant before removal.
• Remove all traces of the old manifold gaskets before installing the headers.
• Inspect cylinder-head sealing surfaces, manifold studs and threads before installation.
• Trial-fit the headers before completing the downstream exhaust fabrication.
• Check clearance around the automatic transmission, steering, suspension, starter motor and bodywork.
• Protect the painted header surfaces during installation.
• Re-tighten the header/manifold bolts after approximately 500km to help maintain a reliable gasket seal.

Why Good Headers & Exhaust Systems Matter

At 4,000 rpm, the 3.4L 5VZ-FE V6 processes a substantial volume of intake air and hot exhaust gas. A well-designed header and exhaust system helps reduce unnecessary restriction and improve exhaust scavenging, torque, throttle response and usable engine performance.

Warranty & Compliance

Frequently Asked Questions

Which Toyota Hilux does WILD276A suit?
WILD276A is designed for selected Toyota Hilux VZN167 and VZN172 4WD models from 2002 to 2005 fitted with the 3.4L V6 5VZ-FE petrol engine and automatic transmission.

Does WILD276A fit a manual transmission Hilux?
No. WILD276A is the automatic transmission application. For compatible manual transmission models see Wildcat WILD276M.

Are WILD276A headers direct fit?
No. Exhaust fabrication/modification is required to complete the installation. Professional installation is recommended.

What size are the Wildcat WILD276A headers?
WILD276A uses 1.58" primary pipes, 2.00" secondary pipes and 2.50" outlets.

What type of header design is WILD276A?
WILD276A uses an interference design developed for street performance applications.

What finish is used on WILD276A?
The headers have a heat-resistant paint finish rated to 600°C.

Are these headers Australian made?
Yes. WILD276A Wildcat Headers are Australian made.
